Square Screen（29.5”, Other Sizes Optional)
| Product Introduction | 1. Support real-time management and publishing on mobile, iPad, and PC platforms. | |
| 2. Support remote upgrade of advertising machine software version and OTA upgrade. | ||
| 3. Support synchronous and consistent playback of advertising machines in the same group, with a synchronization interval of less than 500ms. | ||
| 4. Support remote setting of advertising machine attributes, control of advertising machine volume, rotation angle, time zone, power on/off, etc. through a mobile device. | ||
| 5. Support remote monitoring of advertising machine network status, system status, hardware status, and monitoring of advertising machine playback content. | ||
| 6. Support various forms of scrolling subtitles and bullet screens, and the font, size, and content of subtitles and bullet screens can be edited. | ||
| 7. The scheduling supports multiple priorities and supports priority levels such as filler/normal/insert/urgent messages. | ||
| 8. The scheduling supports multiple looping modes, such as daily/weekly/monthly looping. | ||
| 9. It can support various media such as video/images/marquee/ subtitles/RSS/components/PPT/PDF. | ||
| 10. Support the use of self-built templates and the ability to modify them with one-click on mobile devices. | ||
| Display parameters | Model | 29.5" |
| Panel Type | a-Si TFT-LCD | |
| Display area | 529.4mm(H)x529.4mm (V) | |
| Display Proportion | 1：1 | |
| Resolution | 2160X2160 | |
| Display Color | 16.7M | |
| Dot Pitch | 0.2451× 0.2451 mm | |
| Brightness | 350CD | |
| Contrast | 3000：1 | |
| Viewing angle | 178° | |
| Response Time | 8ms | |
| Refresh Rate | 60Hz | |
| Manual Language | Chinese/English | |
| System Parameters | CPU | ARM Cortex-A17 |
| DDR | 2G DDR3 | |
| Flash | 8G EMMC | |
| Wifi | 2.4G WIFI | |
| 802.11b : DQPSK, DBPSK, CCK | ||
| 802.11g/n : 64-QAM,16-QAM, QPSK, BPSK | ||
| Interface support | TF Card× 1/USB× 2 DCIN×1 OTGX1 MICX1 | |
| System Version | Android 7.1 | |
| Power | Input Voltage | ～AC 100-240V 50/60Hz |
| Maximum power consumption | 38W | |
| Standby power consumption | ≤0.1W（Board only） | |
| Other | storage temperature | -20--60° |
| Amplifier power | 1×1.3W | |
| Product Size | 559.8× 559.8×44mm | |
| Product Weight | 10.4KG | |
| Attachment | AC power adapter | AC 12V/5A |
